DN10 1/2 Inch Manual Diaphragm Valve PC Hand Wheel

MOQ:	20

Thông tin chi tiết

Place of Origin:

China

Chứng nhận:

3A ISO

Làm nổi bật:

Mô tả sản phẩm

Operating temperature	-10℃~120℃,sterilization temperature150℃(MA*20min)
Valve body material	Product contact partSUS316L,Product contact partSUS304
Size	DN10,1/2''
Hand wheel material	PC hand wheel
Sealing material	Material,EPDM,PTFE,Silicone
Surface polishing accuracy(μm)	External electromagnetic polishing,Internal mirror polishing Ra<0.4μm
Operation	Manual, Pneumatic
Pressure	0-10bar
Application	Dairy food,beverage,pharmacy,cosmetic,chemical,etc
Connection	Welding, flange,quick,threaded
Angle of installation	According to the structural characteristics of the valve, it is recommended to install the valve at 30 angles, which is conducive to complete drainage after cleaning the valve and is not easy to cause liquid retention inside the valve.
